Remote Control 3 Armed Full Height Turnstile SUS304 Stainless Steel Single Lane

Shenzhen Rona Intelligent Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Remote Control 3 Armed Full Height Turnstile SUS304 Stainless Steel Single Lane

Brand Name : RONA

Model Number : RNCF20238Y-3

Certification : CE,ISO

Place of Origin : China Shenzhen

MOQ : 1 unit

Price : negotiation

Payment Terms : T/T,

Supply Ability : 2000 units Per Month

Delivery Time : 7-15 working days

Packaging Details : wooden cases packing

Dimension : L1500*W1350*H2200 (mm)

Communications Interface : RS485, TCP/IP

Matrial : 304# 201# 316# Stainless Steel(Optional)

Contact Now

Single Lane 3 Armed Full Height Turnstile SUS304 Stainless Steel Remote Control


Product Descriptions:

  • RNCF20238Y-3 Full Height Turnstile can be installed in the entrance of construction sites, factories, stadiums, ministries, prisons and any locations where security is a high priority. The passage way of RNCF20238Y-3 can be either with 120° or 90° positioned arms, as three or four armed. All kind of access control system like card reader, biometric reader, remote control unit or push button can be entegrated to RNCF20238Y-3 via simple dry-contact.Once the access right is granted, user should touch slightly to RNCF20238Y-3 arm in order to make it rotate. After the arms complete one turn, RNCF20238Y-3 is automatically locked.

All-around Personal Safety Protection:

  • In case of power cut, RNCF20238Y-3 Full Height Turnstile is unlocked to allow free rotation of the arms in both sides enabling easy evaqucation of the area and preventing getting stuck inside the gate.

Technical Specifications:
Input interface: relay dry contact signal; +12V level signal or pulse width>100ms 12V pulse, drive current>10mA
The inductive card reader dimension: equipped with the standard mounting brackets, or tailor.
Operation voltage: AC220V±10% 50Hz±10%
Communications Interface: RS485, distance ≤1200m (standard) ; Available to connect with external CAN BUS and Ethernet (Optional)
Relative humidity: ≤90% Non-condensing
Working Temperature: -10℃ ~ 70℃
Card Reader mounting: Card readers may be mounted on the surface of the barrier, or the card readers may be mounted flush mounted. There is an output to interlock the card.


Services Provided:

  • All items have 12 month quality guarantee.
  • OEM/ODM available: Custom design shape, color and logo.
  • Special discount of our distributors or agents in their area.
  • Packing in standard export carton, suggest you pack it by wooden case to protect the products.
  • Fast delivery: sample order in stock, 5~7 days for bulk production.
  • Payment: we can accept T/T, .
